Caterpillar CAT326 used excavator earthmoving machine used excavator for sale
Advantages and highlights:
1.Offer Test Report of Professional Institute.
2.Details Of Maintenance And Repair Items Included.
3.Price Concessions.
4.Official Factory Sourcing.
5.Reconditioning Directly From XCMG.
6.Vehicle Condition of Perfection.
7.XCMG Official Endorsement.
8.SGS Provides The Third-Party Inspection Certificate.
Description | Unit | Parameter value | |
Operating weight | kg | 25800 | |
Bucket capacity | m³ | 1.54 | |
Engine | Model | Engine | Cat C7.1 |
Output power | kW | 151 | |
torque/speed | N.m | 106 | |
Displacement | L | 7.01 | |
Travel speed（H/L) | km/h | ||
Main performance | Gradeability | % | |
Rotary speed | r/min | 9.9 | |
Ground pressure | kPa | 35000 | |
Bucket digging force | kN | 166 | |
Arm digging force | kN | 121 | |
Oil Capacity | Fuel tank capacity | L | 474 |
Hydraulic tank capacity | L | 310 | |
Engine oil capacity | L | 147 | |
Appearance size | Overall length | mm | 10060 |
Overall width | mm | 3190 | |
Overall height | mm | 3000 | |
Width of platform | mm | ||
Length of crawler | mm | 2950 | |
Overall width of chassis | mm | ||
Wheel base of crawler | mm | ||
Crawler gauge | mm | 2590 | |
Clearance under counterweight | mm | 1060 | |
Min. ground clearance | mm | 440 | |
Min. rear-end swing radius | mm | 3000 | |
Max. digging height | mm | 9680 | |
Working scope | Max. dumping height | mm | 6650 |
Max. digging depth | mm | 6820 | |
Max. vertical wall digging depth | mm | 5340 | |
Max. digging reach | mm | 10120 | |
Worker Standard | Bucket capacity | m³ | 1.54 |
